Nitrogen Generators
Nitrogen Generators NiGen GC

• Capable of delivering 500 Nml/min with purity > 99.9995%
• Available in a standard version and the HC version which ensures 100% removal of hydrocarbons (< 0.1 ppm for applications with high-sensitivity detectors)
• Very high purity nitrogen guaranteed by the PSA system with the exclusive CLAIND Fast Purity patent
• Facility to serve up to 12 FIDs/NPDs with makeup gas or up to 7 ECDs or 5 S/S
• High performance available with an extremely competitive purchase price
• Facility for integration with a dedicated air compressor

Nitrogen Generators NiGen LCMS

For the LC/MS analyzers line, the Brezza series offers dedicated NiGen LCMS Nitrogen Generators.
The LC/MS analyzers made and marketed by various manufacturers do not all share the same requirements in terms of type, flow rate, pressure and purity of the gases needed for their operation.
That's why the NiGen LCMS series of generators in the Brezza line was created to meet the needs of all LC/MS analyzers on the market.
• Available in 3 models:
o 40.1 version with output of 40 Nl/min and integral compressor
o 40.0 version with output of 40 Nl/min without compressor
o 100 version with output of 100 Nl/min without compressor
• Able to supply up to 4 LC/MS analyzers
• Purity up to 99.9%
• High purity nitrogen guaranteed by the PSA system with the exclusive CLAIND Fast Purity patent: unlike conventional hollow fiber membranes, the Carbon Molecular Sieves (CMS) utilized in PSA technology allow almost total adsorption of hydrocarbons, thereby limiting analytical interference on samples and spectrum
• The 50 liter Nitrogen storage tank and the internal compressed air accumulator mean less frequent air compressor starts, thereby reducing noise levels and maintenance requirements
• High performance available with an extremely competitive purchase price
• also the 40.1 version, which is equipped with a special built-in full oil-free compressor, features minimum noise levels thanks to a series of sound-proofing and antivibration features, while compressor servicing is only necessary after 14,000 hours of duty
• Facility for connection to the factory compressed air line in the -0 version (without compressor)
• Facility for interface with a PC and/or Ethernet network using a special accessory

Nitrogen Generators NiGen HF

• Capable of delivering 3 Nl/min with purity of 99.9995%
• Very high purity nitrogen guaranteed by the PSA system with the exclusive CLAIND Fast Purity patent
• High performance available with an extremely competitive purchase price
• HF-1 version with special built-in full oil-free compressor
• Extremely quiet thanks to special soundproofing and antivibration measures

Nitrogen Generators for Thermal Analysis and ELSD NiGen MICRO

• Capable of delivering up to 5000 Nml/min with purity of up to 99.5%
• High purity nitrogen guaranteed by the PSA system with the exclusive CLAIND Fast Purity patent
• High performance available with an extremely competitive purchase price
• Facility for integration with a dedicated air compressor
• For ELSD, Applied Biosystems LCMS and Thermal Analysis
